Print Technology

Inkjet, drop-on-demand, piezoelectric

Ink

Proprietary polymer pigment water-based iX inks and ColorGrip

Drop Size

Variable, multi-level

Print Resolution

1,200 x 1,200 dpi

Print Speed

iX3200: 320 A4 duplex images per minute
( ~9,145 SRA3 duplex images per hour / ~8,350 B3 duplex images per hour)

iX2100: 210 A4 duplex images per minute
(~6,035 SRA3 duplex images per hour / ~5,505 B3 duplex images per hour)

Duty Cycle
(per month)

iX3200: 1,000,000 - 10,000,000 A4 impressions
iX2100: 1,000,000 - 7,000,000 A4 impressions

Paper Substrate

Commodity coated and uncoated papers including specialties

Configuration

(Standard)

1 x Paper Input Module (PIM Flex XL)
1 x High Capacity Stacker

PIM Capacity

4,500 sheets A4 (80 gsm) per PIM
23,400 sheets A4 (80 gsm) with 3 PIMs and Duo Paper Trays

HCS Capacity

2 x 3,000 sheets (80  gsm) per HCS

Paper Weight

Uncoated: 60 - 350 gsm / Coated : 90 - 350 gsm

Paper Size

Tray 1 and 2: 203 x 203 mm - 320 x 488mm
Tran 3 and 4: 203 x 208 mm - 350 x 508 mm

Controller

PRISMAsync

Data Stream

PDF 1.7 (Extension Level 3), PDF-X (APPE 4.x RIP support), PDF/VT (Level 1), PostScript, PPML 2.2, IPDS IS/3, SRA PCL6

Job Submission

LPR, Hot-Folder (WebDAV), socket (streaming), JDF/JMF, IPP 2.0, remote PDF driver

Connectivity

Internal: 1 x 10 Gigabit Ethernet / External: 2 x 1 Gigabit (10/100/1000 Base-T)

Power Usage

Printing = 24.4 kW / Idle = 13.2 kW / Sleep = 0.9 kW

Compressed Air

5 - 12 bar, dry and oil free

Water Supply

Reverse osmosis water system

Temperature

20 - 26°C (optimal range)

Humidity

30 - 50% (optimal range)

Operating Noise

Printing = 72 dB; Idle = 61dB

Dimension

8,800 mm (L) × 2,750 mm (W) x 2,300 mm (H)

Weight

Approx. 8,000 kg
